PM Group NATURE (Green) PVC Layflat Hoses-IrriFinder

PM Group SKY PVC (Blue) Lay Flat Hose

This made in TURKEY braided layflat hose is perfect for tough heavy duty applications: Sprinkler, WaterTransport, Mines, lrrigation, Construction, etc., for use with high tension and high working pressure.

Applications: Medium pressure up to 6-10 bar application in;

Sprinkler Irrigation
Industrial
Water Transfer
Construction

Construction: 3-Ply Polyester Yarns. Both tube and cover are extruded simultaneously to obtain maximum bonding.

Working Temperature: -21ºC to 70 ºC

For liability purposes, if temperature exceeds 45°C the working pressure will go down.

Technical Specifications

• Perfect connection polyester yarn by high technology
• Environment friendly raw materials / free of industrial waste.
• UV provides long lasting life
• Decreases stretching when exposed to pressure.
• Anti-delamination, anti-expansion, anti-elongation, anti-torsion system
• Perfect for irrigation and water transportation.
• Stretching resistant traction resistant.
• Perfect adhesion between layers.
• Flat hose on fiexible pvc impregnated in the textile polyester sock, with only one layer.
• Single layer at hose manufactured with anti-delamination system and with reinforced traction capacity.
• Colour: green
• Packaging: PE Shrinkage film or box only when the at hose is supplied with fıttings.
• Our products do not contain carcinogenic DOP

Size		Inner Diameter	Thickness	Std Length	Working Pressure (at 20c)	Weight
mm	inch	mm	mm	m	kg/ ㎠ (bar)	g/m
53	2"	53	1.7	100	10	330
78	3"	78	1.9	100	6	570
