GEM-A3P-3W-Latch-Brass-Solenoid-Valve

GEM-A3P-3W-Latch-Brass-Solenoid-Valve

GEM-A3P-3W-Latch-Brass-Solenoid-Valve

Baccara-GEM-A3P-3W-Latch-Brass-Solenoid-Valve

Latch-brass-solenoid-valve-body-only

Latch-brass-solenoid-valve-body-only-normally-closed-or opened

GEM-A3P | Latch w/Brass Solenoid Valve

Manufacturer: Baccara

Be the first to review this product

Size

:

1/8" and 1/4" BSP

Function

:

3 Way, NC, NO

Valve Operation

:

Direct Operated

Body Material

:

Brass

Seal

:

NBR

Pressure Range

:

6 - 12 bar

Media

:

Air, water, oil

* Valve Function

* Size

* Orifice

* Latch Type

Description By Manufacturer
Reviews
Contact Manufacturer
Unit Conversions
Manufacturer Info

Technical Data

Function	2, 3 Way NC
Ports size	1/8" and 1/4" BSP
Orifice size	See table
Pressure range	See table
Kv (l/min)	See table
Temperature range	Fluid : -10ºC to 80ºC (no freezing) Ambient : -10ºC to 50ºC
Materials in contact with media	Manual override: Plastic Main Valve: Brass Solenoid Operator: Stainless Steel AISI 300 & 400 series Seals: NBR, EPDM
Media	Air, water, oil
Coil type	Latch
Standard protection class	IP65 with connector * Option : IP68 (please refer to GEM-BP Coil)

Max. Pressure (bar) 2W NC table

Orifice (mm)	08	1 2	1 6	2 0	2 4	30	40
Pressure (bar)	16	16	16	16	16	16	8
Flow factor Kv(l/min)	05	1 1	1 7	2 5	35	45	5

Max. Pressure (bar) 3W NC table

Orifice (mm)	08	1 2	1 6	2 0	2 4	30
Pressure (bar)	16	16	16	14	10	6
Flow factor Kv(l/min)	05	1 1	1 7	2 5	35	45

GEM-A3P-LATCH-DIMENSIONS

G75-A3P-2W-Plumbing-Diagram

G75-A3P-2W-Plumbing-Diagram
