Aytok Minithings Plastic Disc Filter

Aytok MPD-MPE filters are used effectively to meet the filtering needs of water required for low-capacity usage areas. Due to its small size, it is used effectively in many areas. It is widely used in fields such as garden irrigation systems, fertilization systems, and small-scale cooling water filtration.

General Characteristic

Body Material : PP
Cartridge Material: Disc Cartridge(PP)
Maximum Working Pressure : 8 Bar (116 PSI)
Maximum Working Temperature: 60 °C/ 140 °F
Filtration Degree: 130 micron

Technical Specifications

mini-plastic-disc-filter-technical specifications mini-plastic-disc-filter-diagram

CODE	D	M	T	D1	H	K	FLOW	FILTRATION AREA	WEIGHT
CODE	inch			mm			m³/h	cm²	kg
MPD3/4	3/4		1/2	68	190	160	5	185	0,45
MPD10	1		1/2	68	190	160	6	185	0,45
MPD10S	1		1/2	96	230	220	10	325	0,75
MPD15	1½		1/2	96	230	220	15	325	1
MPD15S	1½	1/4	1/2	120	280	270	20	550	1,5
MPD20	2	1/4	1/2	120	280	270	25	550	1,5

Filter Cleaning

The pressure difference between the inlet and outlet is observed manually from the manometers. If the pressure difference increases, the water flow is cut off and the system is stopped. Then remove the cover and take out the cartridge. For screen filter, the screen can be directly cleaned with pressurized water and reassemblied. For disc filter, loosen the the disc cartridge screw and clean the disc with pressurized water, then the filter can be reassemblied.
