MDF-MSF-Series-Mini-Disc-Screen-Filter

Mini Plastic Disc Filters

Manufacturer: Armas Valves & Filters

Be the first to review this product

Body Material	:	Plastic
Internal Material	:	PP – PRGF
Maximum Working Pressure	:	8 bar
Maximum Working Temperature	:	60°
The Filtration Sensitivity	:	130 micron
Cartridge	:	Disc
Made in	:	Turkey

Manufacturer part number: MDF

* Size

3/4" (20 mm)
1" (25 mm)
1 1/2" (40 mm)
2" (50 mm)

Description By Manufacturer
Reviews
Contact Manufacturer
Unit Conversions
Manufacturer Info

Download Manual FIlters Catalogue

Technical Specifications

		mm	inch	mm	mm	mm	inch	inch	m³/h	cm²	kg
	Product Code	D		D1	H	K	M	T	Flow Rate	Filter Surface	Weight
	MDF 3/4	20	3/4"	95	165	340	1/4”	1/2”	3	155	0.31
	MDF 1	25	1"	95	165	340	1/4”	1/2”	5	155	0.31
	MDF 3	31	1 1/4"	145	250	340	1/4”	1/2”	8	403	0.42
	MDF 4	38	1 1/2"	145	250	340	1/4”	1/2”	10	403	0.86
	MDF 5	50	2"	145	250	340	1/4”	1/2”	12	403	0.9

Code	Size (Inch)	Filtr. Area (cm²)	Capacity (m³/h)
MDF4	1½"	400	10
MDF5	2"	400	12
